Fast Draw (Gottlieb-1975) (FizX3.3)

Fast Draw (Gottlieb - 1975)
IPDB No. 828

NOTES:

MOD UNAUTHORIZED WITHOUT EXPLICIT PERMISSION FROM THE AUTHOR

Cinematic for credit reel by kind permission of Greywolf

You can access to the menu with the Special2Key.
You can toggle (by the toggle HUD key) the HUD reel.
If you use arrows for plunger (optional), you have to use arrow down and arrow up (customisable) in order to pull or push the plunger.

RULES:

Insert coin or press credit button to reset machine. Repeat for additional players.
Points are scored as indicated.
Completing A-B-C sequence and either group of drop targets lights corresponding hole alternately for special. Completing both groups of drop targets resets center drop target for 5000 points.
Completing A-B-C sequence doubles bonus value (3 balls game).
Bonus scores double on last ball or triple if A-B-C sequence is completed.
A-B-C sequence and drop targets reset after each ball.
Center bumper scores 10 or 100 points (for 5 balls game, 1000 points for 3 balls game) when lit.
Bonus is scored after completion of ball in play.
A tilt does not disqualify a player.
Matching last two numbers in score to number that appears on back glass after game is over scores 1 replay.

IPDB HIGHLIGHTS:

Date Of Manufacture: April, 1975

Production: 8,282 units (confirmed)

Notable Features: Flippers (2), Pop bumpers (3), 5-bank drop targets (2) with trip arm, Standup targets (4), Kick-out holes (2), Dual inlanes, Half-moon credit window. End-of-ball bonus. No slingshots.
Maximum displayed point score is 99,990 points per player.
Replay wheel maximum: 9

Hitting all ten drop targets during a ball in play not only resets all targets but a drop target trip coil mounted on each drop target chassis operates a trip arm having four trip arm wireforms to immediately drop all eight yellow targets, leaving only the two center black targets to hit for 5000 points each. Dropping both black targets resets all ten targets then again trips the eight yellow ones to leave only the black targets for 5000 points, and this pattern will repeat until the end of the ball in play. All ten targets reset at start of next ball with none tripped.

Design by: Ed Krynski

Art by: Gordon Morison

Notes:

The 2-player version of this game is Gottlieb's 1975 'Quick Draw'.
We previously showed a date for this game of March 17, 1975. The new date is per Gottlieb documentation.
We have increased our confirmed production run quantity to include 237 Sample games produced in 1975 that were not part of the former quantity per handwritten documentation identified by Wayne Neyens as coming from Bob Malvasio, a draftsman for Gottlieb whose initials RHM can be found on schematics
