About This File

MatrixGifForge is a visual editor for creating animated GIFs for Matrix displays used in Pinup Popper Table selection . Import your logo, combine multiple background and foreground effects, customize colors, motion, shaders, and animations in real time, then export optimized GIFs with live preview. No coding required—just load, tweak, and create unique LED animations in minutes.

Use this tool in combination with my MatrixMx1Forge tool.



Examples:

8ba.gif.5e9ff66bf924d1e340e0db054863a218.gifair.gif.196978f7df5fc86cbd905a1739bba6c5.gif

air.gif.2c8d421b7a51485218634b446cda0ff8.gifal.gif.41582b5dd445a2515f263399c662cc67.gif

ap.gif.5a62db563e94a3e09c1521eeb41d96c9.gifafm.gif.6da3b5c8b22ad674fdfaf0abc580fda6.gif

ap.gif.9e85125b39a10a4a99dd11a4d505adf1.gifav.gif.dc48eb7ece85dac7bea2566df3470af2.gif

ave.gif.b11d90a744bf2e7021358feb79586210.gifbad.gif.e91dee943817db3234031e483471de8a.gif




More Examples:

bl.gif.e9c719ebb140847db2b50f3db65ea0a9.gifbutt.gif.243a73178bb2a2e9ecf0813207ffb42e.gifbigb.gif.c26781900684dd1193c6b5385bb5edcc.gifbbh.gif.524f4ea545c9b79cbf88ad55e806afe2.gifbig.gif.810378b202d2318cd37762287431b1b1.gifblackr.gif.295b109bf33763249fadf98d06355637.gifblood.gif.7d026fb2704175e32dc4074aa50b62cc.gifbeans.gif.7b47bfd1808a5f165d5dd4be3593f5ef.gif

What's New in Version 4   See changelog

Released

New

- "Scroll big logo " - a new block under the preview for dense, tall or
  multi-line logos that turn to mush when squeezed onto 96x16. Instead of
  shrinking the logo to 16 px, it keeps the logo full-size and slides a
  96x16 window across it, so every line stays big and readable as it
  passes. Pick a direction with the round buttons (Off, Up, Down, Left,
  Right). Every logo scrolls in every direction - tall, wide or square -
  and the logo runs the whole way through, from fully off-screen on one
  side to fully off-screen on the other. The preset effect you have chosen
  (background, shader, overlay) scrolls along with it, and every Size and
  Readability slider applies too, so a scrolling logo tunes exactly like a
  static one. A speed slider sets how many frames the pass takes.

- 250 new presets that always keep your logo's own colours (the nl and nl2
  families). Every one uses brightness-only effects - waves, scans,
  ripples, breathe, strobe, twinkle, chase, layered shaders, plus moving
  backgrounds and overlays - so the cyan, red or gold of your logo stays
  exactly as it is; the effect only changes how bright each pixel is, never
  its colour. All are visually distinct from each other and from the older
  presets, bringing the collection to around 415.

- The presets that recoloured the whole logo were removed - both the ones
  that forced it to a single colour (all white, all gold...) and the ones
  that replaced its colours with a rainbow, fire or plasma. Everything that
  remains keeps your logo's real colours.


Changed
- The Size "fit" dropdown now has five options that each do something
  visibly different: 'fit' shows the whole logo in proportion, 'height'
  fills the height, 'width' fills the width (and may run off the top and
  bottom), 'stretch' fills the whole panel, 'original' leaves it 1:1.
  Before, three of the choices did the same thing.

- "Surprise me" now draws evenly across the whole collection and remembers
  the last 40 picks, so it reliably shows something different every time
  and you can see the full range instead of the same handful.
